POWER SOLUTIONS
BATTERY SYSTEMS
Customized battery solutions for your applications
ENERGY TECHNOLOGY
Energy Storage, Batteries and Packs
From simple single-cell applications to complex battery packs with intelligence and custom Battery Management Systems (BMS).
Our Expertise
Every cell chemistry has its pros and cons. We support you in evaluating the ideal technology for your product. Our many years of experience in the development of battery packs and power supply systems make us an ideal partner.
We source cells or complete packs and accompany you through the approval process. We are also happy to assist you in the development of custom protection circuits and Battery Management Systems (BMS).
Our Services
Battery Pack Development
Li-Ion, LiFePO4, LTO, SIB, NiMh, etc.
BMS Design
Cell monitoring, Balancing, Thermal Management
Interfaces
I²C, SMBus, CAN, UART, RS485
Firmware
Energy Management & State Diagnosis
Validation
Testing & Certification Support
Comparison of Cell Technologies
| Criterion | LCO | NCM | LTO | LFP (LFe) | SIB | Semi-Solid | LIC | Supercap |
|---|---|---|---|---|---|---|---|---|
| Energy Density [Wh/kg] | ~180–220 | ~200–280 | ~60–80 | ~90–160 | ~100–160 | ~250–350 | ~20–50 | ~3–10 |
| Discharge Rate (max.) | ~1–2C | ~3–5C | ~10–30C | ~5–10C | ~1–2C | Variable | ~100C+ | >10,000C |
| Safety | Low | Medium | Very high | High | High | Very high | Very high | Very high |
| Cycle Stability | Medium | Medium/High | Very high | High | High | High | Very high | Extremely high |
| Charging Speed | Slow | Medium | Very fast | Medium/Fast | Medium | Fast | Extremely fast | In seconds |
| Temperature Behavior | Sensitive | Stable to 60°C | Very stable | Good | Cold stable | Very good | Excellent | Excellent |
| Raw Materials | Cobalt critical | Co/Ni critical | Titanium (neutral) | Non-critical | Available | Variable | Neutral | Non-critical |
